For sterile processing applications requiring 7,200 to 14,400 gallons per day (GPD).

The ANSI/AAMI ST108:2023 standard sets clear water quality requirements for processing medical devices, and meeting it takes a complete system, not a single piece of equipment. Extreme Water Services supplies full water purification packages that cover pretreatment, purification and post-treatment, sized to your facility’s daily water demand. Better water quality improves patient safety and helps instruments and reprocessing equipment last longer.

System Features

Pretreatment

• Carbon pre-filter for chlorine removal
• Sediment pre-filter for particulate removal
• Anti-scalant injection feed to prevent hard water scale on the reverse osmosis membranes

Reverse Osmosis (RO) System

• Smart monitoring with real-time alarms and automatic system shutdowns
• Programmable standby flush
• High-efficiency membranes for top-quality water
• Open-frame design for easy servicing

Polishing Deionization (DI)

• Final polish with either a Silex deionizer or DI exchange tanks serviced by a local DI exchange provider
• RO and DI bypass headers keep the system running during maintenance or shutdowns

Storage Tank & Distribution

• Storage tank with sealed lid
• Distribution pump sized to system requirements, with shutdown on empty storage tank
• Submicron vent filter
• Distribution loop return manifold
• Pressure relief valve
• Distribution loop return flow meter
• Sample port
• Distribution loop to drain valve
• Internal spray nozzle

Ultraviolet (UV) Light

• Controls bacteria growth in the purified water storage and distribution system
• Online monitor measures output intensity and alarms when the lamp needs to be replaced

Endotoxin Ultrafiltration

• 0.2 submicron endotoxin cartridge
• Installed after the UV unit to remove endotoxins from the purified water storage and distribution system

Alarm Panel

• Monitors system operating conditions
• Includes RO alarm, low storage tank alarm and water conductivity alarm
• Remote alarm for continuous monitoring outside the water room

Included With Every System

• Installation kit
• Water system label kit
• AAMI ST108 validation water testing
• Designed for easy disinfection

Talk to Our Water Treatment Team

Not sure which capacity your sterile processing department needs? Contact Extreme Water Services and our team will review your water usage and recommend a system sized for your facility.
